Industrial Reverse Osmosis Systems
Deploying high-recovery RO membranes for extreme TDS reduction, desalination, and the generation of ultra-pure water for critical industrial processes.
Ultra-Pure Water Generation
Our Reverse Osmosis (RO) Plants are meticulously engineered to remove dissolved salts, organics, and micro-particles from feed water. They serve as the critical backbone for high-purity industrial requirements.
- High-rejection semi-permeable spiral wound membranes.
- Energy-efficient high-pressure multistage pumps.
- Automated Antiscalant Dosing for extended membrane life.
- Integrated Clean-In-Place (CIP) systems for maintenance.
Maximum Recovery, Minimum Waste
Operating an RO plant shouldn't mean wasting water. We design systems utilizing high-recovery stages and energy recovery devices to minimize reject water volume and operational power costs.
- Scalable skid-mounted designs for easy capacity upgrades.
- Advanced PLC/SCADA integration for continuous parameter monitoring.
- Exceptional resistance to membrane fouling and scaling.
- High-grade SS304/SS316 piping for ultra-pure fluid handling.
Industries Served
We deploy RO systems where absolute precision in water quality is non-negotiable for product integrity and process safety.
Power Plants
Demineralized boiler feed water to prevent turbine and tube scaling.
Electronics & Semi
Generating ultra-pure water (UPW) required for silicon wafer manufacturing.
Beverage Production
Ensuring absolute product consistency and taste profile across bottling batches.
Pharmaceuticals
Providing Water for Injection (WFI) grade purification stages.
Our RO Process Flow
1. Feed Assessment
Detailed Silt Density Index (SDI) and TDS testing of the source water.
2. Pre-Treatment
Utilizing sand/carbon filters and micron cartridge filters to protect membranes.
3. Pressure Boosting
Engineering specific high-pressure pump configurations to overcome osmotic pressure.
4. Membrane Separation
Forcing water through semi-permeable polyamide membranes to reject dissolved solids.
5. Permeate Polishing
pH adjustment and optional UV sterilization or Mixed Bed (MB) deionization.
6. Reject Management
Routing high-TDS reject water for safe disposal or secondary ZLD processing.
Typical RO Specifications
| Parameter | Industrial Expectation | S K Technologies Capability |
|---|---|---|
| Total Dissolved Solids (TDS) Rejection | > 95% | 98.5% to 99.8% Rejection Rate |
| Recovery Rate | 50 - 60% | Up to 80% with multi-stage / concentrate recovery |
| Membrane Types | Standard Bracket | Brackish Water (BWRO) and Sea Water (SWRO) |
| Automation | Basic | Fully automated with SCADA and remote monitoring |
| Operating Pressure | Variable | Optimized up to 1000 psi based on feed salinity |
